PowerBird 1100WSE PSU provides greatest freedom of cable routing and customization with fully modularized cables, and maximum 87% efficiency. PowerBird is truly a build of craftsmanship that is designed to meet today's most demanding gaming machine and expectations of system builders.
  • Features
  • Details
  • Cables
  • Awards & Reviews
  • ATX 12V 2.3 and EPS 2.92 compliant
  • High efficiency >80% from 20%-100% load and typical up to 87% efficiency
  • Full range input with active power factor correction (PF>0.99)
  • All Sleeved Cables
  • Large thermally controlled 120MM double bearing fan
  • Guaranteed to deliver rated specifications at 40 Degree C
  • Design to support Dual / Quad Core CPU, Intel Core i7 CPU, CrossfireX and NVIDIA SLI
  • 12V1 - 12V6 design to provide superior performance
  • Modularized cable management to eliminate clutter and improve airflow inside the case.
  • Safety agency approval / EMI approvals: CE, CB, TUV, FCC, CUL, CCC and BSMI certified
  • 3 year Warranty from Topower
DC to DC technology
-Deliver the most stable performance with extreme high efficiency.
-Yield perfect regulation
- Balance load sharing
powergood

PowerGood LED indicator
Self-test for normal operation.

Cable Management
-Flexible to plug in any bridge.
6 sets of 12V rails design
Eliminate clutter and improve airflow inside the case
case coating Comply with EuP Compliant
-Meet the energy and resource consumption standards required by European Union's EuP Directives .


100% 105¢XC Japan-made Solid-state Capacitors
- high-quality Japanese capacitors for maximum durability and reliability comparing to other electrolytic capacitors on the market
- last longer even under the harshest operating conditions
S2M -Double forward circuit
-High efficiency up to
88%
-Full range > 85%



Dimensions: (W X H X D) 5.8"X 3.5"X 6.825" (150mm x 86mm x 175mm)

Model Number: TOP-1100W-PBA
115-240Vac / 15-10A / 50-60Hz

PowerBird 1100

Voltage

3.3V

5V

12V1

12V2
12V3
12V4
12V5
12V6

-12V

5Vsb

Max spilt current

30A

30A

19A

19A
19A
19A
19A
19A

1.0A

6.0A
81A

Max combine Power

200W
972W
12W
30W

1060W
40W




1100W
ATX 24pin & 20 pin
X1
ATX 4+4 pin
X1
atx_4pin
ATX 4 pin
X1
PCI-Express 6+2 pin
X2
6pin
PCI-Express 6 pin
X2
SATA
X8
Molex 4 pin
X6
FDD
X1
